Product description
Featuring a flame-retardant PC outer casing and core components with magnetic latching relays, our design sustains continuous 25A+ loads through overspec pure copper wiring. This ensures fail-safe operation – high load 25+ thermal stress casing without combustion.
AULIFANTS LP405 SMART SOCKETS
Usage Bill Monitor, Full Control
Real-Time Monitoring
Accumulated Energy, 0.01kWh precision. Electricity Cost, Auto-calculated with triple rates. Switch Status, Real-time relay position. Working Time. Electrical Parameters: Live Voltage, 0.1V resolution (80-300V), Live Current, 0.01A accuracy (±1%). Instant Power and Power Factor (PF).
Timer and Usage Limits
Timer for scheduled ON/OFF, Daily/weekly automation. Auto-adjust with sunrise/sunset. Energy Saver, Shut down heavy loads at peak rates. Usage limits for kWh Countdown, Auto cutoff at preset value. Safety Guard, Prevent device overburning (e.g. heaters), Budget Lock, Precise monthly cost control.
Summer/Winter dual-period time-of-use billing
dual-period time-of-use (TOU) billing for summer and winter periods. Within each period, users can independently set peak, valley, and flat electricity rates (three-tier rate structure). The device provides 24/7 automatic energy cost calculation, ensuring accurate billing year-round.
Dual-Mode Smart Control
Cloud Remote Control, Global access via Tuya/Smart Life apps, Instant switching command. Real-Time Sync, Device status pushed to phone instantly. Local Manual Control: Physical Button, Dedicated ON/OFF key on device. Zero-Latency, Magnetic relay instantaneous action.
Over/Under Voltage Protection, Overload Protection
The Over/Under Voltage Protection monitors the supply voltage and automatically disconnects power to safeguard equipment in case of abnormally high or low voltage, this feature can be combined with an Auto-Reclose function to automatically restore power once voltage returns to normal.
Offline Data Logging
Decade-Long Data Vault, 512MB MicroSD Card Standard (free with machine purchase). Full-Parameter Logging: Voltage/Current/Power/Rates/PF/Working Time/Events. Dual-File Architecture: ddmmyy-D.csv, Minute-level metrics (1 record/min), ddmmyy-E.csv, State-change events (on-demand).
Please pay special attention to the following points:
Regarding of micro SD card
Use a small-capacity micro SD card (e.g., 512MB, 1GB, 2GB) with Class 6 (Standard Speed).
Pre-use Reminder
Format the card to FAT32 before use.
Safety Notice
Do not insert/remove the card while the device is powered on.
Rate Setting
Rate settings support up to three decimal places.
Model LP405 Voltage AC110V~AC240V Current <25Amp Frequency 50/60Hz Accuracy Rate 1.0 Pulse 1600imp/kWh Network WiFi Over Load Protect Default 25Amp, Setting available Over Under Voltage Protect Default off, Setting available Relative Humidity < 95% Temperatures 24 ~ 122℉ (-10℃~50℃) Size 137 x 75 x 36 mm Power consumption <2Watt
[Real-Time Monitoring]: Energy Tracking: Accumulated Energy, 0.01kWh precision. Electricity Cost, Auto-calculated with triple rates. Status Monitoring: Switch Status, Real-time relay position. Working Time, Minute-level load duration. Electrical Parameters: Live Voltage, 0.1V resolution (80-300V), Live Current, 0.01A accuracy (±1%). Instant Power and Power Factor (PF).
[Dual-Mode Smart Control]: Cloud Remote Control: Cross-Platform, Global access via Tuya/Smart Life apps, Instant switching command execution. Real-Time Sync, Device status pushed to phone instantly. Local Manual Control: Physical Button, Dedicated ON/OFF key on device. Zero-Latency, Magnetic relay instantaneous action. Offline Operation, Works without internet.
[Industrial 25 heavy-duty, Magnetic Latching Relay]: Safe for high power appliances. Supports heavy-duty devices like AC/heaters (25A/5500W), exceeding standard sockets (typically ≤16A). Zero holding power, maintains state without continuous power like normal relay. Explosion-proof, physical dual -coil structure eliminates arcing, >100,000 switching cycles, 95% energy saving vs traditional relays.
[Timer and Usage Limits]: Timer for scheduled ON/OFF, Daily/weekly automation. Scene Sync, Auto-adjust with sunrise/sunset. Energy Saver, Shut down heavy loads at peak rates. Usage limits for kWh Countdown, Auto cutoff at preset value. Safety Guard, Prevent device overburning (e.g. heaters), Budget Lock, Precise monthly cost control.
[Offline Data Logging]: Decade-Long Data Vault, 512MB MicroSD Card Standard (free with machine purchase). Full-Parameter Logging: Voltage/Current/Power/Rates/PF/Working Time/Events.
[Tuya & Smart Life App Ecosystem]: Dedicated Integration: Tuya & Smart Life Certified, Full-featured SDK implementation. Custom UI: Device-specific panels. Voice Ecosystem Connectivity: 3rd-Party Speaker Support, Works with Alexa/Google Home (user-linked).
[Over/Under Voltage Protection and Overload Protection]: The Over/Under Voltage Protection monitors the supply voltage and automatically disconnects power to safeguard equipment in case of abnormally high or low voltage, this feature can be combined with an Auto-Reclose function to automatically restore power once voltage returns to normal. The operating thresholds (trip points) for both protection functions are customizable by the customer.
[Summer/Winter (DST) dual-period time-of-use billing]: dual-period time-of-use (TOU) billing for summer and winter periods. Within each period, users can independently set peak, valley, and flat electricity rates (three-tier pricing structure). The device provides 24/7 automatic energy cost calculation, ensuring accurate billing year-round. Both the time ranges for the summer and winter periods and the corresponding peak, valley, and flat rates within each period are fully customizable by the customer to match local utility tariffs or individual needs.
[Screen Orientation Flip]: the function specifically designed to address display inversion issues caused by socket installation direction. Regardless of whether the socket is installed conventionally or inverted, users can adjust the screen content to an upright, readable orientation.
[2.0-inch TFT color display]: (320×240 QVGA) for clear, high-quality visuals. [PC (Polycarbonate) flame-retardant housing]: Premium material for non-ignition safety.
Amazon Customer –
Big money saver
Worked great for my swimming pool save me a bunch of money this summer not running the pump all day long
toby –
Reliable Smart Plug Power Meter for Monitoring AC/Heater Usage
This smart power meter is easy to use—just plug it in and you can instantly see voltage, current, and power consumption. The color screen is clear, and the readings update quickly. The WiFi monitoring through the app is very convenient, especially for tracking the energy usage of high-power devices like heaters or AC units. Overall, it’s stable, accurate, and a useful tool for monitoring electricity usage.
P. Harley –
Major flaws.
Don’t bother. Poorly written code. The firmware was not properly debugger. Entering data into fields is a waste of time. Field entry for adding unit $ per kwatt does not work. Loose power and all accumulative data is lost. Amazon is not screening this crap like Wal-Mart. If it’s discounted it likely has a flaw inherent that doesn’t pose a safety problem but is a flaw that renders the product saleable but with limited use. Like this POC.
Mikal –
Great device
This device is amazing. Slight complimentary device for any demanding power. My sockets are rated 15 amps. This is rated for 25 amps making easy to use demanding power on obsolete sockets. I use it for a miner is draws 1700 watts continuously and it didn’t trip the breaker. Its energy monitor feature is great.Ok Update it industrial but the plastic will melt. It melted on me with a continuous load of 1700w it messed the socket up but my miner was not damaged. The plastic melted they will see i sent it back for a replacement. I dont think my sockets couldn’t handle the juice but and the monitoring device was drawing all the current and it wasn’t passing through fast enough and overloaded the device started it melting. It was still working but severely damaged. I found out because of the smell. I thought it was my avalon Q I was freaking out. Then I looked down at the socket and seen a orange glow. And ripped it out of there. It may have been something I did wrong. I’ve ran it on 874w and 1374w and 1700w the 1700w was where it gave way. If you do get this device get a cord that will isolate the device from the wall that way you won’t damage your other device or wall socket.Socket=cord small extension =monitoring device= small extension cord = output device. To isolate a fire it will damage the cords.
Ben –
Worth the money
Easy setup and works great, including the app.
shepherdguy –
Great Utility Use Meter
This meter does more than I thought it could do. It tracks energy usage by hour, day, month, and year. It even allows you to enter in your utility rates so that it can track how much was spent on the outlet that it is being used with. This is very convenient.
AuxPowerUnit –
Good for remote power monitoring and on-off control.
I had a different brand of plug-in watt meter previously. Then I got this one because it allows remote monitoring via internet-connected apps. The meter plugs into a wall outlet, and my monitored device is plugged into the front of the meter. Data about the voltage, current, and wattage are sent via the internet to either of two free apps: Smart Home or Tuya Smart. Both apps allow me to remotely turn the monitored device on or off. The meter worked well when I tested it on my bench polisher. I anticipate trying it on heavier loads later.There were some minor problems with this meter which caused me to subtract one star. First, the power button on mine was stuck, even while new out of the box. It feels like some glue got under the dome switch. I was able to unstick the button by wiggling it back and forth many times. Second, the bottom of the case protrudes too far down, so this meter blocks the use of the second outlet on a typical dual outlet. Third, each cellphone app starts by connecting to the closest wi-fi network. But after connecting to the meter, the app insists on switching to a 5GHz connection. If 5GHz wi-fi is not available, the Smart Home App refuses to monitor this device. That is puzzling, because the data rate from this monitor is refreshed very slowly, about once every 4 seconds.
Dragon9 –
Useful little bugger!
There are a couple of these plug in meters, and this one, for design and function, is by far the better one. Integrates with SmartLife, a plus if you already have that. Useful statistics and full or partial resets. Worked quite a bit with technical support on some readings and design issues and they were very responsive and quick to fix! Future upgrades planned…
